    EN10305-2 E355 OD10 Optional Size Welded Steel Tube , Carbon Steel Precision Steel Tube

    Ask Lasest Price
    Brand Name : Hongbao
    Model Number : Hongbao-WTX01
    Certification : DNV, ISO, TS16949
    Delivery Time : Within 50 days if production
    Price : Negotiable
    Payment Terms : L/C, T/T
    • Product Details
    • Company Profile

    EN10305-2 E355 OD10 Optional Size Welded Steel Tube , Carbon Steel Precision Steel Tube

    EN10305-2 E355 OD10 Optional Size Welded Steel Tube , Carbon Steel Precision Steel Tube


    Description:

    Cold drawn welded pipe, it is the production of one of the best choice of the multistage hydraulic cylinder tube, its process and precision seamless steel tube cold drawing process, is to use precision resistance welding (ERW) precision drawing, manufacturing the EN 10305-2 eu mechanical cold drawn steel tube welding standard.


    Steel GradeChemical Composition(%)
    Steel nameSteel numberC maxSi maxMnP maxS maxAl min
    E2151.02120.100.050.700.0250.0250.025
    E2351.03080.170.351.200.0250.025-
    E3551.05800.220.551.600.0250.025-

    Application: automotive industry, machine and equipment building


    Size(mm): O.D.:6.0-224.0 W.T.:1-15 L:max 12000


    Delivery State: + C (BK drawn for shine/hard)

    + N (NBK normalized)


    Surface: phosphatized, non-phosphatized, electrolytic zinc coated and chromated


    Marking: Running marking along whole tube


    Additional Testing: Eddy Current Testing, Ultrasonic Testing.


    Precision steel tubes are characterized by:special dimensional accuracy of outer and inner diameters or wall thickness smooth surface resulting from drawing technology defined mechanical properties large dimensional variety


    Process:

    The cold rolled welded tube is produced by drawing ERW (electric resistance welded tube).During this process the sizing (wall thickness, inside and outside diameter), as well as weld integrity and surface finish is closely controlled to produce tube of the required size and mechanical property characteristics.


    Packaging Details:

    Original packaging according to the customers Export standard package in bundled or as required.
    It both ends protected with plastic net Or wooden boxes according to length and destination
    Oiled inside / outside Marking,oil-coating,varnish,end-protection by plastic caps to be confirmed.

    Mill Test Certificate:

    The product is supplied with 3.1.B inspection certificate,according to the standards EN 10204 and ISO 10474.


    Payment

    30% TT in advance, balance before shippment or B/L at sight.
